Description
The Toslon TF520 feature finder, released by Toslon as a direct replacement for the popular best-selling TF500 model. Carrying a number of upgrades and improvements on the original design, including improved higher gain sonar technology bringing you more detail and clarity to your images than ever before. Offering a view of the topography of the swim, and the fish in it, to depths of up to 30m. All outputted onto a 4.3 Inch TFT screen capable of displaying over 65,536 colours helping you get an accurate picture of the swim your in, even in bright sunlight. An ideal upgrade for your bait boat, taking any guesswork out of your rig and bait placement. Now includes monitor battery.
Features
- Wireless digital echo sounder
- Multi-language menu (including English)
- Sensor Cable Length: 50cm
- IPX6 Level Waterproof Casing Design
- Water Temp. Included in Transducer
- Frequency-hopping spread spectrum (FHSS)
- Direct-sequence spread spectrum (DSSS)
- Hardware gain adjustable
- Built in 3S lithium battery charging function
- Stable wireless performance even in bad condition
- Monitor and Display Real-time Voltage of Bait boat Battery
- Sonar Alarms: Fish / Shallow / Low Battery
- Real-time display (no time lag between what the echo picks up and what is displayed on the screen)
- Colour Line technology allows for easy reading of fish and bottom structure (easily identifiable bottom hardness)
- Depth is indicated above each fish symbol
- Sonar alarm: fish, high bottom and low battery (boat battery and echo sounder battery)
- Depth sounder battery level and boat battery level display
- Easy to store with a foldable display in the housing
- Freshwater/saltwater compatible
- Now included... monitor battery
Specifications
- Range: 300m (variable depending on the environment)
- Depth capability: 30m (100ft)
- Radio frequency: 2.4GHz
- RF chain: 20
- RC power: 20dBm
- Sonar frequency: 115kHz
- Sonar Beam Angle: 60 degrees @-10db
- Display size: 4.3" TFT LCD Sunlight Viewable
- Resolution: 480 x 272 pixels - 65,536 color
- Sonar unit size: 15.3cm x 11cm x 4.4cm
- Portable Case size: 26.2cm x 15cm x 9.8cm
- Operating temperature: -10°C and +50°C
Questions and Answers
Q
How easy is this unit to fit to my tolson x boat ?
A
Hi Rich,
It does involve some effort to install one of these. I've put a link to the quick start guide below that gives you the process step by step.
chrome-extension://efaidnbmnnnibpcajpcglclefindmkaj/http://toslon.com/upload/TF520/Quick%20start%20guide%20of%20TF520_V1.1.pdf'
Regards
Tackl
Q
Hi, does the Toslon tf520 come with everything needed for installation?
A
Hi Gerard,
I believe they should, but as we don't keep these physically in our warehouse, I'm unable to check for you. Sorry.
Kind regards'
Tackleuk'
Q
Hi does this work with a waverunner mk 3 . 2.4 ghz . Can it just be plugged into work as im not electical minded. Thanks
A
Hi Richard,
I'm afraid as that is a boat, we don't currently stock, I'm afraid I wouldn't be able to advise. I'd recommend to contact Waverunner directly and they should be able to advise further on what is compatible with the boat.
Kind regards
Tackleuk
Q
What kit comes with the base unit & screen
A
Hi Mick,
You also get a storage case, sensor cable and transducer.
Regards
TackleUK'
'
Q
Can this be fitted to any baitboat I've got a mk1 microcat
A
Hi Lee,
Although we do sell the Angling Technics range, no one here has actually tried attaching one of these feature finders. That being said, the Waverunner boats are available with these as a packaged option so they should be fairly easy to fit. I had a look on the Toslon FB page and they say it just requires you to drill one hole to attach the unit.
"#TF520, latest design from toslon team, better sonar image and easy to use. With a powerful tiny transducer, a
Q
Hi, does this finder come with tripod & ext battery kit plus instructions Regards Dave
A
Hi David,
They don't come with a tripod, just what's shown in the images. There is an additional cable supplied and instructions too.
Regards
TackleUK
Q
When I try to use my Toulon TF520 all I get is a black screen with a few dashes in the top left hand of the screen, what is the problem?
A
Hi Dr Web,
If you bought the item from us, is this the first time you've tried to use it, or has it been working and since stopped? Either way, if you get in touch with our customer services team with this info via our ticket system on our website. They should be able to assist. I've put in a link below.
https://www.tackleuk.co.uk/Contact/NewSupportTicket#anchor
Regards
